Performance Characteristics:
Parameter | Unit | XD133S | |
Weight distribution | Working weight | kg | 13200 |
Front wheel distribution weight | 6600 | ||
Rear wheel distribution weight | 6600 | ||
Compaction performance | Static linear load | N/cm | 305/305 |
Nominal amplitude | mm | 0.3/0.8 | |
Vibration frequency | Hz | 67/50 | |
Exciting force (high frequency/low frequency) | kN | 110/170 | |
Vibration wheel size | mm | 1300×2130 | |
Maneuverability | Speed range | km/h | 0~6,0~8,0~12 |
Theoretical gradeability | % | 35 | |
Minimum turning radius (in/out) | mm | 4470/6600 | |
Swing angle | ° | ±8° | |
Steering angle | ° | ±35° | |
Engine | Rated power | kW | 111 |
Rated speed | r/min | 2100 |
